BMP is one of the leading clear view fencing manufacturers. In China, High-Security Level Clear View Fencing is also called the 358 fence( 3"×0.5"×8 guage), also known as the "prison fence" or anti-climb fence. "358"comes from its measurements 3" x 0.5" x 8 gauge which equates to approx.76.2mm x 12.7mm x 4mm in metric.358 security fences are challenging to penetrate, with the small mesh aperture being effectively finger proof and extremely difficult to attack using conventional hand tools. 358 fences are recognised as one of the most difficult to break through the barrier because it is difficult to climb. It is called security fencing and high-strength fencing.

Features:

Anti-climb: More small opening, no toe or finger holds.
Anti-cut: robust wire and welded joints make cutting very difficult.
High-strength: The supplier's welding technique and process control create a more robust fusion between the wires.

Treatment

358 wire mesh fence is a professional structure designed for high-security environments, combined with a steel framework, coated with heavy zinc or RAL colour powder coating. Hot-dipped galvanised and plastic coated. The colours of plastic-coated are mainly green and black. Each colour is available according to your requirement. as one of the leading clear view fencing suppliers, our clearvu fence is challenging to penetrate. The small mesh aperture is effectively finger proof and extremely difficult to attack using conventional hand tools.

Specification clear view fencing manufacturers

358 security fence
wire diameter	mesh size	Panel(H*W)	Post (length *diameter*thickness)
4mm (8#)     clear view fencing manufacturers recommend hot sale specifications	12.7mmx76.2mm 1/2"x3"	2000mm*2500mm	2700mm*60*60*2.5mm
		2400mm*2500mm	3100mm*60*60*2.5mm
		3000mm*2500mm	3800mm*80*80*2.5mm
		3300mm*2500mm	4200mm*80*80*2.5mm
		3600mm*2500mm	4500mm*100*60*3.0mm
		3600mm*2500mm	4500mm*100*100*3.0mm
		4200mm*2500mm	5200mm*100*100*4.0mm
		5000mm*2500mm	5200mm*100*100*5.0mm
		5200mm*2500mm	6200mm*120*120*5.0mm

Mesh size	Height	Width	Line wire x cross wire	Post length	Nos. Of brackets
76.2x12.7mm     clear view fencing manufacturers	2100	2500/2750/3000	3.0x4.0 4.0x4.0 4.0x6.0	2700	7
	2200	2500/2750/3000		2800	8
	2400	2500/2750/3000		3000	9
	2700	2200/2300		3700	10
	3000	2200/2300		4000	11
	3600	2200/2300		4800	12
	4000	2200/2300		5200	14

Clear view Fencing Post Manufacturers Recommended

	P1-SHS	P2-IPE	P3-RHS	P4-C+F
	Square post	IPE post	Rectangle post	C post with a flat bar
Popular size A	60x60	100x55	60x80	60x80
Popular size B	80x80	100x68	80x100	80x100
Popular size C	100x100	120x74	100x150	100x150
clear view fencing manufacturers recommend Wall thickness of fence post	1.2-1.5mm	1.2-2.0mm	2.5-5.0mm	2.0-5.0
