Cochrane fencing

Product No.：Cochrane fencing
Price：9.68-48.88$ Per kit
Service Life：5-10 years
Packing：Metal Stillage Wrapped with Plastic Film
Colours：All RAL colours for Vinyl Coated One
Customized：Available
Production Time：14 days
Payment Term：TT 30% deposit balance 70% at sight of finished products photo
Certificate：ISO
Materials：Q195 and Q235
Treatement Surface：Hot dipped galvanized ,powder coated ,pvc coated
Online Inquiry

We are a significant Cochrane fencing china supplier in China; we produce high-quality Cochrane fencing; if you are interested in an anti-climb fence post, this article may help you.

1. Cochrane fencing Process

Wire material--wire straighten& cut---welded wire mesh---galvanized---powder coating--packing

2. Cochrane fencing Application

358 Security Fence is a special fencing panel called clear view fencing. With a professional structure designed for high-security environments.358 Security Fence is extensively used when defendable space is paramount; It is designed to provide security and protection for industrial and commercial properties and public utilities. It is also suitable for military, airport, prison or security units with an electronic alarm and detection stems. BMP supplies the highest quality anti-climb fence.

3. Cochrane fencing Feature

358 security fence is the best value for performance, durability and appearance.'358' comes from its measurements3" x 0.5" x 8 gauge which equates to approx. 76.2mm x 12.7mm, Wire Dia: 4mm (Gauge 8), while in recent years, there are also customers asking for 3510 fences which equates to 76.2mm x 12.7mm, Wire Dia: 3mm (Gauge 10). 358 security fence is welded with high-quality carbon steel wire; high weld strength at each intersection makes the fence strong and durable and with the below features:

ANTI-CLIMB

More small openings, no toe or finger holds.no, climb and penetrate.

ANTI-CUT

Robust wire and welded joints make it impossible to cut by conventional bolt or wire cutters.

GOOD VIEWING VISIBILITY

Despite the small mesh aperture, the see-through characteristics remain unimpaired when viewing head-on and even at an angle to the fence. This is particularly important for precise camera surveillance.

DURABLE

Low maintenance and long life resulting from high quality

Details Cochrane fencing

Mesh	Wire Thickness	Surface Treatment	Panel Width	Height
76.2x12.7 mm	Horizontal wire:3.0 ,3.5,4.0mm Vertical wire:4.0mm	Galvanized and Electrostatic polyester coated, or Hot dipped galvanized	2.50mOr 2.20m	1800mm
				2000mm
				2100mm
				2200mm
				2400mm
				2500mm
				3000mm

Height	Length	V-Bends
1800	3000	3
2000	3000	3
2100	3000	3
2400	3000	4
3000	3000	5

Specifications

Wire diameter	Aperture 75mm	Tensile strength	Weld strength
4mm (Vertical) x 3mm (Horizontal) 4mm (Vertical) x 4mm (Horizontal) 3mm (Vertical) x 3mm (Horizontal)	12.7mm high security 25mm medium security 50mm low security	500 - 650 mpa	60% - 80%

Zinc coating
Lightly Galvanised (60g/m²)	Fully Galvanised (275g/m²)	Galfan Coated (220g/m²)
Lightly Galvanised (50g/m²)	Fully Galvanised (255g/m²)	Galfan Coated (195g/m²)
