Clearvu fencing is a popular security fence in South Africa that is strong, durable, and looks good. It is often used in places like factories, warehouses, and prisons to keep people out who aren't supposed to be there. This fence is also used by the military and border control to protect important places. With Clearvu fencing, you can feel safe knowing that your property is secure and won't be damaged or tampered with.

Clearvu fencing specifications in South Africa

Panel Dimensions	Aperture Size (Centers)	Wire Diameter	Horizontal Bands	Flanges	Through Bolt System
3305mm x 1800mm	76.2mm x 12.7mm	3mm/3mm	4x50mm deep V	2×70°x75mm + 2×30° or 2×90°x50mm	Included
3305mm x 2000mm	76.2mm x 12.7mm	3mm/4mm	4x50mm deep V	2×70°x75mm + 2×30° or 2×90°x50mm	Included
3305mm x 2100mm	76.2mm x 12.7mm	4mm/4mm	4x50mm deep V	2×70°x75mm + 2×30° or 2×90°x50mm	Included
3305mm x 2400mm	76.2mm x 12.7mm	Customized	4x50mm deep V	2×70°x75mm + 2×30° or 2×90°x50mm	Included
3305mm x 3000mm	76.2mm x 12.7mm	Customized	4x50mm deep V	2×70°x75mm + 2×30° or 2×90°x50mm	Included

Clearvu Fencing Post Specifications:

Fence Panel Height	Post Length	Post Size	Locking Recess Mechanism	Polymer Cap	Post Finish
1.8m	2.4m	85mmx45mmx85mm taper post or 150mmx75mmx150mm taper post	Included	Included	Galvanized and coated with Alu
2.0m	2.6m	85mmx45mmx85mm taper post or 150mmx75mmx150mm taper post	Included	Included	Galvanized and coated with Alu
2.1m	2.7m	85mmx45mmx85mm taper post or 150mmx75mmx150mm taper post	Included	Included	Galvanized and coated with Alu
2.4m	3.0m	85mmx45mmx85mm taper post or 150mmx75mmx150mm taper post	Included	Included	Galvanized and coated with Alu
3.0m	3.6m	85mmx45mmx85mm taper post or 150mmx75mmx150mm taper post	Included	Included	Galvanized and coated with Alu

Clearvu Fencing Clamps Specifications:

Clamp Type	Dimensions	Material	Wall Thickness
Single Bolt Clamp Plate	50mm x 76mm	Hot Dipped or Black Steel	3.00mm to 5.00mm
Double Bolt Clamp Plate	50mm x 165mm	Hot Dipped or Black Steel	3.00mm to 5.00mm

Note: The dimensions and wall thickness of the clamps can vary based on the specific requirements of the customer.

Clearvu fence panel packing involves a few simple steps to protect the panels during transportation.

Fence Panels Packing

First, a layer of plastic film is applied to the bottom of the pallet to prevent damage. Four metal corners are used to reinforce the panels, and a wood plate is placed on top of the pallet to keep the panels stable. Additionally, a vertical pallet tube is inserted for extra support during transportation.

Fence Post Packing

Clearvu fencing posts are also protected during transportation. Each post is covered with a plastic cap to prevent scratches and other damage. Then, the posts are wrapped in plastic film and placed on a metal pallet for added protection.

Fence Accessories Packing

Finally, the Clearvu fence accessories, including stainless steel nuts and screws, are packaged in an organized manner. The clips are loaded into plastic bags, with five sets in each bag, and 12 bags are placed in a carton box for transportation. With proper packaging, Clearvu fence panels, posts, and accessories can be safely transported and installed for maximum security.
